Key Features

·       16GB DDR4 SDRAM SODIMM, 260-pin small-outline design

·       High-speed performance: Supports DDR4-2666 and DDR4-3200 data rates

·       Single-rank, x64 module with 25.6 GB/s bandwidth at 3200 MT/s

·       On-board SPD EEPROM with I2C interface for presence detection

·       Data Bus Inversion (DBI) for improved signal integrity

·       Operating temperature range: 0°C to 95°C (commercial grade)

·       Halogen-free 260-pin DIMM package

Product Description

The Micron MTA8ATF2G64HZ-3G2E2 is a high-performance 16GB DDR4 SDRAM SODIMM designed for computing applications that demand reliability and speed. Built on Micron’s advanced DDR4 technology, this 260-pin memory module delivers fast transfer rates up to 3200 MT/s with a bandwidth of 25.6 GB/s. Its single-rank x64 architecture, integrated SPD EEPROM, and support for Data Bus Inversion (DBI) ensure compatibility, stability, and efficient signal quality across demanding workloads.

Technical Specifications

Parameter	Specification
Module Density	16GB (2 Gig x 64)
Data Rate	DDR4-2666, DDR4-3200
Module Bandwidth	25.6 GB/s @ 3200 MT/s
CAS Latency	CL22 (3200 MT/s), CL19 (2666 MT/s)
Pin Count	260-pin SODIMM
Rank	Single-Rank (SR)
Operating Temperature	0°C to 95°C (Commercial)
Package	Halogen-free DIMM

Application Scenarios

Ideal for use in laptops, mini-PCs, and embedded systems that require high memory density and dependable DDR4 performance. The MTA8ATF2G64HZ-3G2E2 supports data-intensive applications such as virtualization, CAD, simulation, and multitasking workloads.

Frequently Asked Questions (FAQs)

·       Q: What is the maximum data rate supported by the Micron MTA8ATF2G64HZ-3G2E2 module?

A: This module supports DDR4-2666 and DDR4-3200 data transfer rates, with peak bandwidth reaching 25.6 GB/s at 3200 MT/s.

·       Q: Does this DDR4 SODIMM module support error correction (ECC)?

A: No, the MTA8ATF2G64HZ-3G2E2 is a standard unbuffered DDR4 SODIMM without ECC functionality.

·       Q: What is the advantage of Data Bus Inversion (DBI)?

A: DBI improves signal integrity by reducing simultaneous switching noise on the data bus, which enhances system stability at high speeds.

·       Q: What systems are compatible with this module?

A: It is designed for laptops, small form factor PCs, and embedded platforms that support DDR4 SODIMM modules with speeds up to 3200 MT/s.
