Key Features

·       8GB DDR4 SDRAM SODIMM with 260-pin design

·       Data rates supported: DDR4-3200, DDR4-2666, DDR4-2400

·       Low operating voltage: VDD = 1.2V, VPP = 2.5V

·       Single-rank x64 module with 16 banks

·       Enhanced reliability with on-die termination (ODT) and DBI support

·       Low-power auto self-refresh (LPASR) for power efficiency

·       JEDEC-compliant design with SPD EEPROM support

·       Halogen-free, gold-edge contacts, and fly-by topology for stable signal integrity

Product Overview

The Micron MTA8ATF1G64HZ-3G2E1 is a high-performance 8GB DDR4 SDRAM SODIMM designed for modern computing systems that demand fast data transfer, power efficiency, and stable reliability. Built with DDR4 technology, this module supports transfer speeds up to 3200 MT/s, making it suitable for laptops, embedded systems, and small-form-factor devices requiring efficient memory performance. The 260-pin SODIMM form factor ensures compatibility across a wide range of platforms.

Technical Specifications

Application Scenarios

This Micron DDR4 SODIMM module is designed for use in laptops, small form factor PCs, industrial controllers, and embedded systems. With high bandwidth and power efficiency, it is well-suited for multitasking, data processing, and demanding workloads.

FAQs

·       Q1: What systems are compatible with the MTA8ATF1G64HZ-3G2E1 module?

A1: It is compatible with systems that support DDR4 SDRAM SODIMM modules with a 260-pin connector.

·       Q2: Does this module support low-power operation?

A2: Yes, it supports Low-Power Auto Self Refresh (LPASR) to improve efficiency.

·       Q3: What are the key benefits of fly-by topology in this module?

A3: Fly-by topology improves signal integrity and enables stable high-speed operation.

·       Q4: Is this memory suitable for industrial or extended temperature applications?

A4: Yes, it supports an operating case temperature range from 0°C up to 95°C in extended mode.
