DRAM Module Samsung DDR5 – 24GB

DRAM Module Samsung DDR5 – 24GB

RDIMM | Registered DIMM | Server Application

Samsung DDR5 24GB RDIMM modules are designed for server platforms requiring balanced memory density and stable signal integrity across multi-channel configurations. Based on DDR5 architecture, the module supports higher effective bandwidth compared to previous DDR generations while improving command efficiency and bank group utilization.

Operating at DDR5-4800 class speeds, this 24GB configuration is suitable for entry and mid-tier server builds where samsung ddr5 24gb rdimm deployment is required without fully populating high-capacity DIMM slots.

Architecture and Electrical Characteristics

• DDR5 memory interface with increased burst length and expanded bank structure
• Registered DIMM design to buffer command and control signals
• ECC parity extension for improved data integrity in server environments
• Supports x4 / x8 organization
• Up to 2 ranks per DIMM
• 3DPC configuration support depending on motherboard topology

Compared to earlier DDR4 platforms, DDR5 improves parallelism and internal data handling efficiency. In practical deployment scenarios such as 4800mhz ecc registered dimm configurations, improved signaling stability allows predictable memory behavior under sustained load conditions.

The 24GB capacity per module provides flexibility in channel population planning. It is commonly selected for virtualization nodes, edge servers, or compute appliances requiring balanced capacity rather than maximum-density configurations typical of 64GB or 128GB modules.

Part Number

Technical FAQ

1. When is 24GB RDIMM preferred over 16GB or 32GB?
24GB modules allow intermediate memory scaling when total channel capacity targets do not align with standard 16GB increments. This can optimize cost-to-capacity planning in multi-channel server systems.

2. Does DDR5 RDIMM require platform-level ECC support?
Yes. While the module includes parity-based error correction capability, full ECC functionality depends on motherboard and CPU memory controller support.

3. Is this module compatible with DDR4 slots?
No. DDR5 uses a different pin layout and signaling standard. System compatibility must be verified against DDR5-supported server platforms.
