SKHynix HMAA2GU6CJR8N-XN 16GB DDR4 3200Mhz 1Rx8 PC4-25600 non-ECC Unbuffered CL22 288-Pin DIMM 1.2V Memory Module for Desktop
SKHynix HMAA2GU6CJR8N-XN 16GB DDR4 3200Mhz 1Rx8 PC4-25600 non-ECC Unbuffered CL22 288-Pin DIMM 1.2V Memory Module for Desktop
无法加载取货服务可用情况
SKHynix HMAA2GU6CJR8N-XN 16GB DDR4 3200Mhz 1Rx8 PC4-25600 non-ECC Unbuffered CL22 288-Pin DIMM 1.2V Memory Module for Desktop
Warranty : Lifetime
Condition: New
Images are for illustration purposes only
| Manufacturer | Hynix |
| Manufacturer Part # | HMAA2GU6CJR8N-XN |
| Memory Type | DDR4 SDRAM |
| Capacity | 16GB |
| Data Transfer Rate | 3200MHz |
| Pins | 288 Pin |
| Bus Type | PC-25600 |
| Error Correction | Non-ECC |
| Cycle Time | 0.62ns |
| Cas | CL22 |
| Rank | Rank 2 |
| Voltage | 1.2 |
Features
• Power Supply: VDD=1.2V (1.14V to 1.26V)
• VDDQ = 1.2V (1.14V to 1.26V)
• VPP - 2.5V (2.375V to 2.75V)
• VDDSPD=2.25V to 3.6V
• Functionality and operations comply with the DDR4 SDRAM datasheet
• 16 internal banks
• Bank Grouping is applied, and CAS to CAS latency (tCCD_L, tCCD_S) for the banks in the same or different bank group accesses are available
• Data transfer rates: PC4-3200, PC4-2933, PC4-2666, PC4-2400, PC4-2133, PC4-1866, PC4-1600
• Bi-Directional Differential Data Strobe
• 8 bit pre-fetch
• Burst Length (BL) switch on-the-fly BL8 or BC4(Burst Chop)
• Supports ECC error correction and detection
• On-Die Termination (ODT)
• Temperature sensor with integrated SPD for ECC UDIMM
• This product is in compliance with the RoHS directive.
• Per DRAM Addressability is supported
